  Home >> Motorola Brand >> Wholesale - Motorla Walkie Talkies Mag one A8 2-Way Radio UHF 5W FM transceiver New arrival

Wholesale - Motorla Walkie Talkies Mag one A8 2-Way Radio UHF 5W FM transceiver New arrival [Comments(0)|Leave your Comment]
Item#:12052102573206
Score:37  (Score change Discount Voucher)
Weight:.85 kg.
List Price:$69.00
Price:$37.00
You Save:$32.00
Qty:

Prev:6 Motorola RMU2040 - UHF 2 Watt 4 Channel Radios & 1 Motorola PMLN6384 6 Radio Charger

detail

Related

Comment

Payment

Shipping

Detailed Specification:



This is a original MT MagOne A8 VHF (150-174Mhz) radio. 100% new, factory packed and never been used.

Features:

-Small, Compact and Easy to use
-16 Channels
-12.5/25kHz Channel Spacing
-PL/DPL
-2 programmable quick access buttons
-More than 8 hrs talk time @ 5-5-90 duty cycle
-Battery Saver Mode
-High/Low Transmit Power Selection
-Low Battery Indicator
-Priority Scan
-Nuisance Channel Delete
-Repeater/ Talk around
-Monitor/Stick Permanent Monitor
-Button Lock
-Busy Channel Lockout
-Volume Set
-Time out timer (10-600 secs)
-Tight/ Normal Squelch Selection



General

VHF

UHF

Frequency Range

136-150MHz

150-174MHz

403-425MHz

450-470MHz

Memory Channels

16

Channel Spacing

12.5/25 kHz switchable

Operating Temperature Range

-30C to +60C (Radio)

-20C to +60C (with NiMH battery)

Dimensions (H X W X D)

107mm x 58mm (bottom) x 37mm

Weight

350g

Average Battery Life

@5-5-90% Duty Cycle

>8 hrs

Sealing

Passes rain testing per IPX4

Shock & Vibration

Diecast with impact resistance polycarbonate housing

Passes EIA 603B

Dust & Humidity

Weather resistant housing passes EIA 603B







Transmitter

VHF

UHF

RF Output

High power

5W

Low Power

1W

High power

4W

Low Power

1W

Spurs and Harmonics

-63dBc (-26Bm at 5W: -27dBm at 4W)

Frequency Stability

±2.5ppm

FM Hum & Noise

40dB

Modulation Limiting

<= 5Khz (25KHz)

<= 2.5Khz (12.5kHz)

Audio Response (from 6dB/oct

pre-emphasis, 300-3000Hz)

+1/-3dB

Audio Distortion

at 1 kHz tone, 60%rated max dev.

<5%



Receiver

VHF

UHF

Sensitivity (12dB SINAD)

<-119dBm (0.25μV)

<-117.5 dBm (0.3μV)

Adjacent Channel Selectivity

65dB (25kHz), 60dB (12.5kHz)

Intermodulation

65dB (25kHz), 60dB (12.5kHz)

Spurious Rejection

65dB

Audio Distortion

<5%

Hum and Noise

40dB

Conducted Emission

<-57dBm

Audio Output at <5% Distortion

500mW



Standard packaging include:

Mag One 1200mAh NiMH Battery, PMNN4071

Mag One Spring Belt Clip

Mag One 5.5-hr Charger 230V 50Hz Euro 2p

Mag One Antenna

User Manual

A8 Charger.jpgA8 Battery.jpgA8 Antenna.jpg

Standard packaging include:

Mag One 1200mAh NiMH Battery, PMNN4071

Mag One Spring Belt Clip

Mag One 5.5-hr Charger 230V 50Hz Euro 2p

Mag One Antenna

User Manual
